HT J13/J14

 new  WIFI

This product is a day and night dual purpose monocular infrared Thermal imager suitable for natural observation, search and rescue, outdoor exploration, sea operations, night patrols, personal security, and more.

Multiple parameters and color palettes can be set
Targets were observed and and night

 Product manual 

HD Night Vision, Precision Lock, Rapid Response!

HT J13/J14 High-Performance Thermal Imagers deliver dual-resolution options (384×288/640×512) with ≤50Hz refresh rate for lag-free dynamic target tracking. The 2560×2560 ultra-HD display renders exceptionally detailed thermal imagery, while 1x/2x/4x/8x digital zoom ensures comprehensive long-range observation.

infrared thermogram

Technical Parameter

Model	HT J13	HT J14
Detector type	Vox	Vox
Infrared Image Resolution	384×288	640×512
Pixel Spacing	17μm	12μm
Focal length	54mm
FOV	10.7×8.2
Spectral Range	8~14μm
NETD	≤25mk@25℃, @F/1.0
Frame Rate	≤50Hz
Focusing Mode	Manual
Display Screen	1.03 inch OLED
Visible Image Resolution	2560×2560
Magnification	1X, 2X, 4X, 8X
Diopter Adjustment	±5D
Color Palette	White Hot, Black Hot, Fire Hot, Rainbow, Iron Red, Cold Color
Hot Spot Tracking/PIP	Support
Language	Simplified Chinese, Tradition Chinese, English
Storage Capacity	Built-in 16GB(Available storage space is 13.8GB)
Photograph/ Recording/Microphone	Support
USB Interface	Charge/Image and video export
APP	ISO 11 and higher Version, Android 7.0 and higher Version
Battery Working Time	≥7.5h
Product Size	419×104×70mm
Product Weight	1035g
Other Specifications
Lens		54mm
Detection Distance	Human：1.7m x 0.5m x 0.3m	2550m
	Vehcle：4.5m x 2.0m x 1.5m	6750m
Identification Distance	Human：1.7m x 0.5m x 0.3m	638m
	Vehcle：4.5m x 2.0m x 1.5m	1688m
